PTX10008-PREM3

PTX10008 redundant 8-slot chassis for 115.2Tbps. Includes 2 REs, 6 power supplies, 2 fan trays, 2 fan tray controllers, and 6 switch fabric cards.
BUY NOW
  • Overview
  • Specifications
  • Datasheet
  • Ordering Information

Juniper Networks PTX10000 modular routers were specifically designed to meet new service level agreements in the cloud era. As cloud and 5G trends accelerate network transformation, core and peering networks face exponential traffic growth due to the massive increase in the number of connected devices, presenting operators with the same challenges but at a faster rate. Leading the 400G transition, these modular routers set new benchmarks of scale, flexibility, and reliability with high-performance custom silicon. These platforms share a common set of components and full feature sets, with various 400GbE-capable line cards available to satisfy specific core, peering, data center, and metro-core deployments in the most demanding environments.

  • Scale: Providers may offer backbone connectivity that requires a large number of label-switched paths (LSPs). If they are using Segment Routing or RSVP to take advantage of the traffic engineering (SR-TE/RSVP-TE) functionality, the control plane signaling path must be able to scale in step with the growth of LSPs. This ability to scale is needed for both the primary and backup paths to support redundancy mechanisms like fast re-route (FRR). Today, the total number needed for backbone connectivity is a few million. This type of scaling challenge will be felt by operators who are trying to diversify their portfolios by adding a broader scope of connectivity options; for example, a data center operator who wants to provide cloud connectivity or VPN services to enterprise customers, or an operator of private line service who wants to add a collocation service to its offering.
  • Operational Flexibility: Virtualized services and the explosion of cloud-based applications are creating increasingly erratic traffic patterns. To handle this unpredictability, service providers need architectures that are flexible and dynamic across all layers. Operators today rely on the flexibility and capacity of IP filters to mitigate the impact of increasing denial-of-service (DoS) attacks.
  • Investment Protection: Ensuring operators are investing in platforms designed to last has become imperative to leveraging the next generation of ASIC improvements the industry is offering. The risk of packet drops from rip-and-replace strategies to yearly silicon upgrades severely impacts the reliability of future upgrades.


Table 1.   PTX10000 Line Specifications

Feature

Specifications

PTX10004

Physical dimensions
(W x H x D)

17.4 x 12.2 x 35 in. (44.2 x 33 x 88.9 cm); 42.2 in. (107.7 cm) depth with EMI door

Maximum weight***

271.2 lb (116.7 kg)

Mounting

Front rack mount

Power system rating*

200-240 VAC/50-60 Hz -48 VDC @ 60 A

Typical power consumption**

8.0 kW, 27.3 kBTU/hr with Express4 line cards, fully loaded

Operating temperature

32° to 115° F (0° to 46° C) at sea level

PTX10008

Physical dimensions
(W x H x D)

17.4 x 22.55 x 32 in.(44.2 x 57.76 x 81.28 cm);
39.37 in. (100 cm) depth with EMI door

Maximum weight***

421 lb (191 kg)

Mounting

Front rack mount

Power system rating*

200-240 VAC / 50-60 Hz -48 VDC @ 60 A

Typical power consumption**

12.7 kW, 43.3 kBTU/hr with Express4 line cards, fully loaded

Operating temperature

32° to 115° F (0° to 46° C) at sea level

PTX10016

Physical dimensions
(W x H x D)

17.4 x 36.65 x 35 in(44.2 x 93.09 x 88.90 cm);
42.40 in (107.7 cm) depth with EMI door

Maximum weight***

706 lb (320 kg)

Mounting

Front rack mount

Power system rating*

200-240 VAC / 50-60 Hz -48 VDC @ 60 A

Typical power consumption**

25.9 kW, 88.3 kBTU/hr with Express4 line cards, fully loaded

Operating temperature

32° to 115° F (0° to 46° C) at sea level


PTX10008-PREM3

Table 1.   PTX10000 Line Ordering Information

Product Number

Description

PTX10004 Premium and Base Units

PTX10004-PREM3

PTX10004 redundant 4-slot chassis for 57.6Tbps. Includes 2 REs, 3 AC/HVDC or DC power supplies, 2 fan trays, 2 fan tray controllers, and 6 switch fabric cards.

PTX10004-PREM2

PTX10004 redundant 4-slot chassis.  Includes 2 REs, 3 AC/HVDC or DC power supplies, 2 fan trays, 2 fan tray controllers, and 4 switch fabric cards.

PTX10004-BASE3

PTX10004 base 4-slot chassis.  Includes 1 RE, 3 AC/HVDC or DC power supplies, 2 fan trays, 2 fan tray controllers, and 3 switch fabric cards.

PTX10008 Premium and Base Units

PTX10008-PREM3

PTX10008 redundant 8-slot chassis for 115.2Tbps. Includes 2 REs, 6 power supplies, 2 fan trays, 2 fan tray controllers, and 6 switch fabric cards.

PTX10008-PREM2

PTX10008 redundant 8-slot chassis. Includes 2 REs, 6 AC/HVDC/DC power supplies, 2 fan trays, 2 fan tray controllers, and 4 switch fabric cards

PTX10008-BASE3

PTX10008 base 8-slot chassis. Includes 1 RE, 6 AC/HVDC/DC power supplies, 2 fan trays, 2 fan tray controllers, and 3 switch fabric cards

PTX10008-PREM3-SON

PTX10008 8-slot chassis for 14.4T LC, including 1 RE running SONiC, 6 AC/HVDC/DC power supplies, 2 fan trays, 2 fan tray controllers, and 6 switch fabric cards.

PTX10008-PREM2-SON

PTX10008 8-slot chassis for 14.4T LC, including 1 RE running SONiC, 6 AC/HVDC/DC power supplies, 2 fan trays, 2 fan tray controllers, and 4 switch fabric cards.

PTX10008-BASE3-SON

PTX10008 8-slot chassis for 14.4T LC, including 1 RE running SONiC, 6 AC/HVDC/DC power supplies, 2 fan trays, 2 fan tray controllers, and 3 switch fabric cards.

PTX10016 Premium and Base Units

PTX10016-PREM3

PTX10008 redundant 16-slot chassis for 230.4Tbps. Includes 2 REs, 10 power supplies, 2 fan trays, 2 fan tray controllers, and 6 switch fabric cards.

PTX10016-PREM2

PTX10008 redundant 16-slot chassis. Includes 2 REs, 10 AC/ HVDC/DC power supplies, 2 fan trays, 2 fan tray controllers, and 4 switch fabric cards.

PTX10016-BASE3

PTX10008 base 16-slot chassis. Includes 1 RE, 10 AC/HVDC/DC power supplies, 2 fan trays, 2 fan tray controllers, and 3 switch fabric cards.

PTX10000 Routing Engines

JNP10K-RE1-E-BB

PTX10000/JNP10000 RE X8 with Junos Evolved, 64G, base bundle

JNP10K-RE1-E-R

PTX10000/JNP10000 RE X8 with Junos Evolved, 64G, redundant

JNP10K-RE1-E

PTX10000/JNP10000 RE X8 with Junos Evolved

JNP10K-RE1-S128-BB

JNP10000 RE with SONiC, base bundle

JNP10k-RE1-E128-BB

PTX10000/JNP10000 RE X8 with Junos Evolved, 128G, base bundle

JNP10k-RE1-E128-R

PTX10000/JNP10000 RE X8 with Junos Evolved, 128G, redundant

JNP10k-RE1-E128

PTX10000/JNP10000 RE X8 with Junos Evolved, 128G

JNP10K-RE1-S128

JNP10000 RE with SONiC

PTX10004 Switch Fabric

JNP10004-SF3-BB

PTX10004/JNP10004 switch fabric card supporting up to 14.4 Tbps LC, base bundle

JNP10004-SF3-R

PTX10004/JNP10004 switch fabric card supporting up to 14.4 Tbps LC, redundant

JNP10004-SF3

PTX10004/JNP10004 switch fabric card supporting up to 14.4 Tbps LC

PTX10008 Switch Fabric

JNP10008-SF3-BB

PTX10008/JNP10008 switch fabric card supporting up to 14.4 Tbps LC, base bundle

JNP10008-SF3-R

PTX10008/JNP10008 switch fabric card supporting up to 14.4 Tbps LC, redundant

JNP10008-SF3

PTX10008/JNP10008 switch fabric card supporting up to 14.4 Tbps LC

PTX10016 Switch Fabric

JNP10016-SF3-BB

PTX10016/JNP10016 switch fabric card supporting up to 14.4 Tbps LC, base bundle

JNP10016-SF3-R

PTX10016/JNP10016 switch fabric card supporting up to 14.4 Tbps LC, redundant

JNP10016-SF3

PTX10016/JNP10016 switch fabric card supporting up to 14.4 Tbps LC

PTX10000 Express4 Line Cards

PTX10K-LC1201-36CD

36x400GbE/36x200GbE/36x100GbE/36x40GbE line card [JNP10K-LC1201]

PTX10K-LC1202-36MR

4x400GbE and 32x100GbE [JNP10K-LC1202]

S-PTX10K-144C-A1-3

SW, PTX10000 14.4T RTU Adv1 Lic, 3-year term, with SW support

S-PTX10K-144C-A2-3

SW, PTX10000 14.4T RTU Adv2 Lic, 3-year term, with SW support

S-PTX10K-144C-P1-3

SW, PTX10000 14.4T RTU Prem1 Lic, 3-year term, with SW support

S-PTX10K-144C-P2-3

SW, PTX10000 14.4T RTU Prem2 Lic, 3-year term, with SW support

S-PTX10K-144C-A1-5

SW, PTX10000 14.4T RTU Adv1 Lic, 5-year term, with SW support

S-PTX10K-144C-A2-5

SW, PTX10000 14.4T RTU Adv2 Lic, 5-year term, with SW support

S-PTX10K-144C-P1-5

SW, PTX10000 14.4T RTU Prem1 Lic, 5-year term, with SW support

S-PTX10K-144C-P2-5

SW, PTX10000 14.4T RTU Prem2 Lic, 5-year term, with SW support

S-PTX10K-144C-A1-P

SW, PTX10K, 14.4T, Adv1, without SW support, perpetual

S-PTX10K-144C-A2-P

SW, PTX10K, 14.4T, Adv2, without SW support, perpetual

S-PTX10K-144C-P1-P

SW, PTX10K, 14.4T, Pre1, without SW support, perpetual

S-PTX10K-144C-P2-P

SW, PTX10K, 14.4T, Pre2, without SW support, perpetual

S-PTX10K-48C-A1-3

SW, PTX10K, 4.8T, Advanced 1, with SW support, 3 year

S-PTX10K-48C-A2-3

SW, PTX10K, 4.8T, Advanced 2, with SW support, 3 year

S-PTX10K-48C-P1-3

SW, PTX10K, 4.8T, Premium 1, with SW support, 3 year

S-PTX10K-48C-P2-3

SW, PTX10K, 4.8T, Premium 2, with SW support, 3 year

S-PTX10K-48C-A1-5

SW, PTX10K, 4.8T, Advanced 1, with SW support, 5 year

S-PTX10K-48C-A2-5

SW, PTX10K, 4.8T, Advanced 2, with SW support, 5 year

S-PTX10K-48C-P1-5

SW, PTX10K, 4.8T, Premium 1, with SW support, 5 year

S-PTX10K-48C-P2-5

SW, PTX10K, 4.8T, Premium 2, with SW support, 5 year

S-PTX10K-48C-A1-P

SW, PTX10K, 4.8T, Adv1, without SW support, perpetual

S-PTX10K-48C-A2-P

SW, PTX10K, 4.8T, Adv2, without SW support, perpetual

S-PTX10K-48C-P1-P

SW, PTX10K, 4.8T, Pre1, without SW support, perpetual

S-PTX10K-48C-P2-P

SW, PTX10K, 4.8T, Pre2, without SW support, perpetual

PTX10004 Fan Tray and Controller

JNP10004-FAN2-BB

JNP10004 fan, Gen2, base bundle

JNP10004-FAN2

JNP10004 fan, Gen2

JNP10004-FTC2-BB

JNP10004 fan tray controller, Gen2, base bundle

JNP10004-FTC2

JNP10004 fan tray controller, Gen2

PTX10008 Fan Tray and Controller

JNP10008-FAN2-BB

JNP10008 fan, Gen2, base bundle

JNP10008-FAN2

JNP10008 fan, Gen2

JNP10008-FTC2-BB

JNP10008 fan tray controller, Gen2, base bundle

JNP10008-FTC2

JNP10008 fan tray controller, Gen2

PTX10016 Fan Tray and Controller

JNP10016-FAN2-BB

JNP10016 fan, Gen2, base bundle

JNP10016-FAN2

JNP10016 fan, Gen2

JNP10016-FTC2-BB

JNP10016 fan tray controller, Gen2, base bundle

JNP10016-FTC2

JNP10016 fan tray controller, Gen2

PTX10000 Power Cables

CBL-PWR2-L6-30P

Power cord, JNP10000 AC2 L6-30P

CBL-PWR2-L6-30P-RA

Power cord, JNP10000 AC2 RA L6-30P

CBL-PWR2-330P6W

Power cord, JNP10000 AC2 IEC309-330P6W

CBL-PWR2-330P6W-RA

Power cord, JNP10000 AC2 RA IEC309-330P6W

CBL-PWR2-332P6W

Power cord, JNP10000 AC2 IEC309-332P6W

CBL-PWR2-332P6W-RA

Power cord, JNP10000 AC2 RA IEC309-332P6W

PTX10000 Power Modules

JNP10K-PWR-AC2-BB

JNP10000 5000 watts AC/HVDC power supply base bundle

JNP10K-PWR-AC2-R

JNP10000 5000 watts AC/HVDC power supply redundant

JNP10K-PWR-AC2

JNP10000 5000 watts AC/HVDC power supply

JNP10K-PWR-DC2-BB

JNP10000 5000 watts DC power supply base bundle

JNP10K-PWR-DC2-R

JNP10000 5000 watts DC power supply redundant

JNP10K-PWR-DC2

JNP10000 5000 watts DC power supply

PTX10004 Front Panels

JNP10004-FRPNL-BB

PTX10004/JNP10004 front panel, base bundle

JNP10004-FRNT-PNL

PTX10004/JNP10004 front panel

JNP10004-FRPNL1-BB

PTX10004/JNP10004 front panel with filter*, base bundle

JNP10004-FRPNL1

PTX10004/JNP10004 front panel with filter*

JNP10004-FLTR

PTX10004/JNP10004 replaceable filter*

PTX10008 Front Panels

JNP10008-FRPNL-BB

PTX10008/JNP10008 front panel, base bundle

JNP10008-FRNT-PNL

PTX10008/JNP10008 front panel

JNP10008-FRPNL1-BB

PTX10008/JNP10008 front panel with filter*, base bundle

JNP10008-FRPNL1

PTX10008/JNP10008 front panel with filter*

JNP10008-FLTR

PTX10008/JNP10008 replaceable filter*

PTX10016 Front Panels

JNP10016-FRPNL-BB

PTX10016/JNP10016 front panel, base bundle

JNP10016-FRNT-PNL

PTX10016/JNP10016 front panel

JNP10016-FRPNL1-BB

PTX10016/JNP10016 front panel with filter*, base bundle

JNP10016-FRPNL1

PTX10016/JNP10016 front panel with filter*

JNP10016-FLTR

PTX10016/JNP10016 replaceable filter*
