Product Overview

Aruba 9200 Series Campus Gateways, Deliver enhanced Wi-Fi scalability and security to the meet enterprise networking demands at the Edge. Engineered for mission-critical environments, the Aruba 9200 Series delivers high performance, seamless roaming, consistent policy enforcement, and always-on connectivity – even during upgrades.

Enterprise-class performance

Aruba 9200 Series Campus Gateways are modern Wi-Fi appliances that scale to support up to 2,048 APs and 32K devices. Delivers 24×7 reliability, live upgrades, and always-on connectivity. Zero touch provisioning reduces the need for on-site IT support.

Investment protection

No more overprovisioning or frequent hardware refreshes. Enterprises benefit from tier-based pricing to unlock more capacity when needed. 9200 Series Campus Gateways are also available with HPE Greenlake as a Service.

Powerful security enforcement

Ensure consistent policy enforcement via dynamic segmentation. Granular rules can be defined for any user, application, or device – even IoT. Streamline management with unified policies across wired and wireless networks.

Features

Campus gateways to meet enterprise requirements at the Edge

Scalable for medium and large enterprises

Highly-scalable appliance for Wi-Fi performance at the Edge – up to 2,048 APs and 32K devices.

Live upgrades

Always on support to provide business continuity in mission-critical environments.

Tier-based licensing

Investment protection with silver and gold add-on licenses to unlock more capacity when needed to meet growing demands – without replacing your appliance.

L2/L3 roaming

Supports tunneling so that two disparate networks can connect directly to one another, for seamless L2/L3 roaming.

Redundancy and clustering

Can be deployed with N+1 or NxN redundancy for performance and scale.

IoT ready

Integrated device profiling improves IoT visibility and works with ClearPass Policy Manager.

Table 1. Aruba 9200 Series Gateways Specifications

Performance and capacity	BASE HARDWARE	W/ SILVER LICENSE	W/ GOLD LICENSE
Maximum campus or remote access points	512	1,024	2,048
Maximum concurrent users/devices	16,384	24,576	32,768
Maximum VLANs	4,096	4,096	4,096
Active firewall sessions	2,015,291	2,015,291	2,015,291
Concurrent GRE tunnels	8,192	16,384	32,768
Concurrent IPsec sessions	16,384	24,576	32,768
Concurrent SSL sessions	8,192	8,192	8,192
Concurrent tunneled ports	8,192	12,288	16,384
Firewall throughput (Gbps)	20	30	40
Wired bridged throughput (Gbps)	20	30	40
Encrypted throughput GRE (Gbps)	20	30	40
Encrypted throughput 3DES (Gbps)	20	27	29
Encrypted throughput AES-CBC-128 (Gbps)	20	30	38
Encrypted throughput AES-CBC-256 (Gbps)	20	30	39
Encrypted throughput AES-CCM (Gbps)	20	28	30
Encrypted throughput AES-GCM-128 (Gbps)	20	30	40
Encrypted throughput AES-GCM-256 (Gbps)	20	30	40
